Hobart GPU-600 Series User Manual

OM-2244 / Operation and Maintenance Manual
DCS-600/ Series 500082 / Solid State Transformer-Rectifiers
December 15, 2014
Chapter 2-3
Page 1
Section 3
Scheduled Maintenance
1) General
The ITW GSE GPU is designed to be as maintenance free as possible. Therefore, there are few
maintenance requirements. Field maintenance of the GPU should be performed only by qualified service
personnel, and should be limited to cleaning and inspection of the unit and its components, as well as, the
replacement of lamps and fuses. All service and repair work, including testing and calibration, should be
referred to the ITW GSE Service Department, to an authorized service shop for ITW GSE equipment, or
to qualified electronic technicians.
2) Maintenance Schedule
As
required
Daily
8 hrs.
1 month
200 hrs.
3 months
600 hrs.
6 months
1200 hrs.
* EXTERIOR CABLES
Inspect equipment
X
Inspect AC input cables
X
Check cable connections (internal)
X
* CONTROLS AND INSTRUMENTS
Check voltmeter functioning
X
Check ammeter functioning
X
Check fan thermostat operation
X
Check indicating lights
X
Check starting current limit functioning
X
Check all output contactor contacts
X
Check power input contactor contacts
X
Check voltmeter & ammeter accuracy
X
Check all wiring and connections
X
Inspect and clean general (light duty)
X
Inspect and clean general (severe duty)
X
* FAN MOTOR
See Lubrication section below
*Suspicious performance overrides timetable
Figure 1 Inspection Schedule
