OM-2244 / Operation and Maintenance Manual
DCS-600/ Series 500082 / Solid State Transformer-Rectifiers
Introduction/ Numerical Index
1) General
The Illustrated Parts List identifies, describes, and illustrates main assemblies, subassemblies, and detail
parts of your ground power unit manufactured by ITW GSE Palmetto Florida.
2) Purpose
The purpose of this list is to provide parts identification and descriptive information to maintenance and
provisioning personnel for use in provisioning, requisitioning, purchasing, storing, and issuing of spare parts.
3) Arrangement
Chapter 4 is arranged as follows:
Section 1 - Introduction
Section 2 - Manufacturer’s Codes
Section 3 - Illustrated Parts List
4) Explanation of Parts List
a) Contents
The parts list contains a breakdown of the equipment into assemblies, subassemblies, and detail
parts. All parts of the equipment are listed except:
(1) Standard hardware items (attaching parts) such as nuts, screws, washers, etc., which are
available commercially.
(2) Bulk items such as wire, cable, sleeving, tubing, etc., which are also commercially available.
(3) Permanently attached parts, which lose their identity by being welded, soldered, riveted, etc., to
other parts, weldments, or assemblies.
b) Parts List Form
This form is divided into six columns. Beginning at the left side of the form and proceeding to the
right, columns are identified as follows:
