Hobart GPU-600 Series User Manual

OM-2244 / Operation and Maintenance Manual
DCS-600 / Series 500082 / Solid State Transformer-Rectifiers
December 15, 2014
Chapter 1-1
Page 12
1
2
3,11
6
5
7
7
8
9
10
4
2
2
1. Rectifier Heat Sink
2. SCR Mounting Clamp
3. Silicon Rectifier (CR1 through CR6)
4. SCR Heat Sink
5. Overload Thermostat (S5)
6. Fan Turn-on Thermostat (S4)
7. Rectifier Mounting Insulator
8. Feedback Shunt (Not Shown) (R12)
9. Positive Base Silicone Diode (CR7)
10. Surge Suppressors (A2, A3)
11. Pin Spring
Figure 7 SCR Heat Sink Assembly of GPU-600
