Hobart GPU-600 Series User Manual

OM-2244 / Operation and Maintenance Manual
DCS-600/ Series 500082 / Solid State Transformer-Rectifiers
December 15, 2014
Chapter 4-3
Page 3
FIGURE
ITEM NO.
ITW GSE
PART NO.
NOMENCLATURE
EFF
UNITS
PER
ASSY.
1
Base Assembly (See Figure 4)
Ref.
2
288267
Panel, Side
2
3
288266
Panel, Top
1
4
283323
Bracket, Cable Hanger
4
5
282658
Label, Warning Clearance
1
6
402025-002
Cable, Output, 28 V , 20 ft
1
[Other Lengths Available]
7
288356
Handle Assembly
A-G
1
288284
…Handle, 5
th
Wheel
A-G
1
288281
…Latch, 5
th
Wheel
A-G
1
288298-001
…Grip, Foam
A-G
2
*
8
288362-001
Cover, Protective, Changeover Board
A,C,F,J,L
1
*
288362-002
Cover, Protective, Changeover Board
B,E,G,H,K
*
9
78B1130
Nameplate, Identification
1
*
10
286441
Label, General
1
*
11
288866
Label, Service
1
*
12
287460
Label, Danger, High Voltage
D,E,H
1
*
13
288322
Label, Fan
D,E,H
1
*
14
288300
Label, Emergency Stop
D,E,H
1
*
15
287547-001
Label, CE
1
*
16
288272
Support, Bridge Mount
J,K,L
2
*
17
288542
Shield, Control Box
1
