Hobart Handler 140 Specifications

Spool Gun 3035-20 #300143
20 ft. (6.1 m) cable and gas hose
Weld 14 gauge – 1/8 in. (1.9 – 3.2 mm)
aluminum with the Handler 140
Threaded nozzle and contact tips
Spool gun conversion kit consisting of
control switch and gas diverter valve
Enclosed wire spool compartment with
internal spool hub tension adjustment
for 4 in. (102 mm) rolls of wire
For .030 – .035 in. (0.8 – 0.9 mm) aluminum,
steel and stainless steel
Rated 150 amps, 60% duty cycle
SGA 100 Spool Gun Control #043856
Required to connect spool gun to the Handler
®
140. Includes 10 ft. (3 m) 115 VAC power cable
and plug, 6 ft. (1.8 m) interconnecting cable,
and 5 ft. (1.5 m) gas hose.
H100S2-10 Replacement MIG Torch
#245924
Comes in 10-ft. (3 m) length with liner for
.030 – .035 in. (0.8 – 0.9 mm) diameter wire.
Portable CO
2 Cylinder
Kit #770626
Includes one 20 oz.
CO
2 cylinder (paintball
style), pre-set regulator
and gas hose, spare
“O” rings, and
mounting hardware.
Small Cart/Cylinder Rack #194776
Designed for portable MIG welders.
Accommodates large and small gas cylinders.
Running Gear/Cylinder Rack #770187
Heavy-duty construction. Accommodates large
and small gas cylinders.
Protective Cover #195186
Weather-resistant nylon resists stains and
mildew while protecting the finish of your welder.
Accessories
3
DUTY CYCLE
1 4 10 20 40 60 10026 808
10
20
40
60
80
100
200
140
DUTY CYCLE %
OUTPUT AMPERES
VOLT/AMP CURVE
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160
0
5
10
15
20
25
30
AMPERAGE
VOLTAGE
RANGE 1
RANGE 2
RANGE 3
RANGE 4
Performance Data

Hobart Handler 140 Specifications

General

Input Voltage	115V
Welding Amperage Range	25-140 A
Duty Cycle	20% @ 90A
Wire Feed Speed Range	40-700 IPM
Weldable Materials	Mild Steel, Stainless Steel, Aluminum
Weight	57 lbs
Processes	MIG (GMAW), Flux-Cored (FCAW)
Input Current	20A
Welding Thickness	24 ga. - 1/4 in.
Input Phase	Single Phase
Maximum Open Circuit Voltage	28V
Wire Size Range	0.023 - 0.035 in
