Hobby Van Exclusive - Intelligent Battery Sensor (Ibs)

Electrical Installations
07-5
45123
Intelligent Battery Sensor (IBS)
(Optional Extra)
Asanoptionalfeature,yourvehicleisequippedwithabattery
sensor.TheIBScontrolmeasurestheavailablecapacityof
thebatteryandalsoindicatesbatteryageing.
Legend
j
DOD display
 Showstheremainingamountoftimeforuseifcurrent
amountofuseiscontinued..
k
Electric power display
 Red=discharge
 Green=charge
l
Electricity as a numerical value
 Example:Currentdischarge:0.1A.
m
Battery ageing
 (SOH=StateofHealth)
 Example:Theoriginalcapacityofthebatteryhasalready
beenreducedby2%.
n
State of charge
 (SOC=StateofCharge)
 Actualstateofchargeofthebattery
 Example:SOC:88%.
