Hobby Van Exclusive User Manual

Electrical Installations
07-3
Control panel
Legend
j
Keyformonitoringthebatteryvoltageofthesuperstruc-
tureandthevehicle.
k
Keyfordisplayingthelevelofliquidinthefreshwater
tank[in%]andforsettingtheparametersthatcanbe
programmed.
l
Keyforprogrammingthesystem.
m
Mainswitch(pressforapprox.2sec.toturnonoroff).
Whenyouswitchiton,thesystemwillcarryoutafunc-
tionaltestandshowallofthesymbolsonthedisplay.
Whenitisgreen,thecorrespondingLEDshowsthatthe
controlpanelison.Ifitisred,itshowsthatanalarmhas
goneoffsomewhere(battery,tank,etc.).
n
Keyforturningthelightsandtheheatingonandoff.
o
Keyforturningthefreshwaterpumponandoff.
p
Keyforswitchingtheoutertentlightonandoff(theouter
tentlightisautomaticallyswitchedoffwhenthemotoris
turnedon).
1 2 3 4 5 6 7
Programming settings
Amongotherthings,thetimeandthealarmfunctioncan
besetintheprogrammingmenu(pleaserefertotheuser
manualformorepossiblesettings).
-Pressthe"PROG"keyforlongerthan2sec.
-Usethearrowkeys(1)and(2)tonavigate.
-Use"PROG"toconrmthesettingyouwishtoset.
-Press"PROG"severaltimestosavesettingsandexitfrom
themenu.
-Toexitwithoutsaving,waitapprox.20seconds.
