Electrical Installations
07-12
1
Circuit breaker
Toprotectthemodularbatteryfrombeingexhaustively
dischargedwhenthemotorhomeisnotbeingused,acircuit
breaker
j
hasbeeninstalled.Whenthisisopened,themo-
dularbatteryiscompleteddisconnectedfromthe12Vmains.
1
Whenthecircuitbreakerisopen,theelectricalinput
stagewillnotengageautomatically.
7.6 Fuse protection of the electric system
Ancillary battery
Themainfuseprotectioniscarriedoutbymeansofa50A
safetyfuse
j
.Thefuseislocateddirectlynexttothebattery.
12V circuits
Fuseprotectioniscarriedoutbymeansoffusesonthe12V
distributionmodule.
The following applies if one of the devices breaks down
• Checkthefuseonthecorrespondingelectriccircuit.
• Replacethefuse.
• Ifthefuseblowsagainpleasecontactyourauthorized
Hobbydealer.
