7.3 Electric power supply
Your motor home has the following connections for electric
powersupply:
- electricmains(a.c.voltage230V)
- caravanbattery(d.c.voltage12V)
Supply via mains connection
The230Vsystemissafeguardedbya2-polecircuitbrea-
kerwitharesidualcurrentoperateddeviceand2x13A.
Theresidualcurrentoperateddeviceislocatedeitherinthe
seatingarrangementbehindthedriver‘sseatorintheclothes
cupboard(dependingonthemodel).Shouldtherebeapower
failure,theautomaticpersonprotectioncircuitinterruptsthe
entire230Velectriccircuit.Inmostcases,suchapowerfai-
lureiscausedbyadefectelectricaldeviceoradefectcord.
•Repairthedefectbeforeyouswitchthecircuitbreakeron
again.
•Ifyoucannotrepairthedefect,consultanelectrician.
Rules for the mains connection:
• Useonlya3x2.5mm²cablewithamaximumlengthof
 25m,aCEEplugandconnectortoconnectthemotor
hometoanexternal230Vmains.
Ifyouareusingacabledrumwithoutprotectionagainst
overheating,theelectriccablemustbecompletelyunw-
oundfromthecabledrum.
• UseonlyplugsandcablesthatmeetCEEstandards.
• First, make the connection to the main socket (1) of the
vehicle.
• Theninserttheotherpluginthelivesocket.
• Followthissequenceinreversewhenyoupullouttheplug.
