Built-in devices
10-4
1
3
5
7
9
40
°
60
°
60
°
Combi
1
2
3
4
5
c
d
f
b
a
g, h
e
1
3
5
7
9
40
°
60
°
60
°
Combi
1
2
3
4
5
c
d
f
b
a
g, h
e
Summer operation
• Turn the rotary switch on the operating panel to Position c
(summer operation 40°C or 60°C).
The green (b) and yellow (g) LEDs will light up. When the
water temperature selected (40°C or 60°C) has been
reached, the burner will turn off and the yellow LED (g) will
go out.
Winter operation
Heating with regulated water temperature
• Set the rotary switch to operating position (e).
• Turn the rotary button (a) to the desired thermostat setting
(1-5).
The green LED (b) for operation lights up and simultane
ously displays the setting for the room temperature
selected.
The yellow LED (g) indicates the warming up phase for
the water. The device will automatically select the perfor-
mance level required. When the room temperature set on
the operating panel has been reached the burner will
