Interior Structure
06-31
Additional belt rack
As an option, the Sphinx models can be tted with a so-
called belt rack facing towards the rear, which increases the
number of seats that can be used while driving from four to
six.
The height of the belt connector can be adjusted manually by
pressing knobs
j
and
k
.
When using the vehicle with 6 people, ensure that the
permissible axle loads as well as the technically permissi-
ble maximum weight is not exceeded.
2
1
Converting the L-shaped seating arrangement
If you wish to use the outer seat in models with an L-shaped
seating arrangement or the seats in the H75 UC model, you
must convert these before you start to drive.
• Remove the seat and back cushions.
• Fold back the cushion cover
j
by 180° and place it on
the crossbench.
• Open the locking bolt
k
swing the supporting wall out by
90° and then shut the locking bolt
k
.
2
1
