22
Rudder Tuning
Maintenance and Care
1
2
3
Align the steering handle
straight.
Tip: Fully tighten the screw
under the steering handle to
keep the handle from turning
during the adjustment.
Starting with the left or right
side, feed the cable under
the screw head on the rudder
drum. Pull the cable so there
is no slack until the cable is
taught. Tighten the screw to
lock the cable.
Repeat for opposite side.
Loosen the screw under the
steering handle 1/4 turn.
Loosen the left and right
screws so the steering
cables are free to move.
Loosen R screwLoosen L screw
Pull cable
& tighten
Pull cable
& tighten
Align rudder pointing straight
Align steering handle pointing straight
1 2
