5 - INDICATION AND USE OF THE WHEEL BALANCER
5.1 - USE OF THE GAUGE INSTALLED IN THE MACHINE
Push back the gauge to the resting position. The machine automatically has detected the mode for steel rims.
For clip-on weights use the gauge in the upper position A.
For adhesive weights use the gauge either in the upper
position A or the lower position B.
Note: Always use the round part of the striker plate.
5.2 - AUTO SELECT
The machine automatically detects the right balancing program for steel, ALU M, and ALU 3M rims.
5.2.1 - AUTO SELECT FOR STEEL RIMS
Pull out the gauge to the edge of the rim. Keep it
there until to display the symbol indicated.
Confi rmation that dimensions are acquired
Set the width indicated on the rim, or measure it
with the calliper (standard accessory).
Perform a measuring spin, turn the wheel to the correct angles, fi x the clip-on weights and perform a control spin.
To balance more tyres of the same type and dimensions, the machine automatically stores the data for the currently
mounted wheel.
