Non-HWM Sape Data Entry
B9000/B9450
If the sape is held stationary for 1 second or more a beep is generated and the offset is shown in the left
display panel. The value is removed from the display when the sape is returned to the home position. If a
measuring run has been performed the results are recalculated and displayed when the sape is returned
to the home position.
B9460
When a sape is removed from the home position the left and right rim positions flash on the weight
application graphic. If a sape is held stationary for 1 second or more a beep is generated and the
relevant LED is disabled. The other LED keeps flashing. When the second position is entered using the
other SAPE the wheel width and diameter are displayed until both sapes are returned to their home
positions. If a measuring run has been performed the results are recalculated and displayed.
HWM Sape Data Entry
When the sape is removed from the home position the appropriate inner plane weight led blinks. This
shows the operator where to apply the arm to the rim. After the sape is stationary for 1 second a beep is
generated, the inner plane position is stored and the outer plane led blinks. At this point the sape can be
returned to the home position. If this is done, the results are not recalculated as the user has only partly
entered the required parameters with the sape. Pressing the offset key enables a beep and resets the
sape to the inner plane so that the inner plane led will flash when the sape is removed. If the offset key
is not pressed and the sape is removed again from the home position, the outer plane led will flash and
the user must enter this value. Holding the sape stationary for 1 second causes the value to be entered,
a beep to be generated and the led to stop flashing. The sape must now be returned to the home
position. If a measuring run has been performed and the rim diameter is within limits for HWM the
results are recalculated and displayed when the sape is returned to the home position.
B9000/B9450
If the rim diameter is less than 12 inches "E12" will be displayed. This is done because it is
not possible to apply weight to the wheel using HWM modes with a rim diameter of less than
12 inches. Pressing the diameter entry key will automatically increase the diameter to the
minimum required value for the HWM mode.
Note: The inner and outer planes must be separated by 3 inches or more. Holding the sape
stationary in an attempt to enter an outer plane offset less than 3 inches from the inner
plane will not store the plane offset.
