HOLMS 300 - Product Facts

3
© HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 5/4/06
HOLMS INDUSTRI AB
MOTALA SWEDEN
HOLMS 300
A
B
1. Centre of gravity
Model 2,0 2,2 2,5L 3,0L
Working width (m)
2,0 2,2 2,5 3,0
Max width (m)
2,2 2,4 2,7 3,2
Max height excluding hook (m)
1,3 1,3 1,3 1,3
Water tank volume (lit)
400 400 400 400
Effective waste volume (ca lit)
360 360 680 680
Weight empty (kg)
455 470 570 650
Weight with filled watertank and container *
1380 1395 1955 2035
Centre of gravity, A in sketch (empty)
150mm 140mm 140mm 130mm
Centre of gravity, B in sketch (empty)
320mm 320mm 340mm 340mm
Max oilflow (l/min)
2000/4000 motors
130/200 130/200 130/200 130/200
Max returnpressure (Bar)
2000/4000 motors
140/105 140/105 140/105 140/105
*) Valid for material with density 1,4-1,5.
Attachment are excluded in all weights and meassures.
