HOLMS 300
Maintenance
After running
• Wash the sweeper which increases the lifetime and makes it
easier to detect eventual leakage or other defects.
• Inspect the sweeper concerning damages on hoses, brush pro-
tectors, springs or frame work. Also check eventual oil leakage.
Important safety regulations to
be noticed
• Be sure the tractor/loader is designed to carry/operate this
attachment with it´s weight.
• Be sure that unqualified persons are not in the operating area
during work or maintenance.
• Always use the quick coupling plugs and put the hose-ends
into the holders when the machine is disconnected, to avoid dirt
coming into the hydraulic system and to protect the hoses.
Change of brushes
Place the supports into driving position and slowly lower the con-
tainer against the ground.
Dismounting of sweeper roll
1. Loosen the hydraulic hose brackets on the bar tube.
2. Remove the four bolts from the gable side.
3. Avoid the bare tube to spring up by holding a foot on the plate
of the support stand, then carefully remove the gable. See pic-
ture 13.
ATTENTION! Avoid clamping.
4. Pull off the sweeper roll from the motor on the other gable.
5. Lift up the machine and take away the sweeper roll.
11. Bracket for hydraulic hoses
12. Removing the bolts
13. Removing gable side
