HX25/25W/27W Service Repair Manual Component Identification
Component List - HX25/25W/27W
2:6
Item No. Description Quantity
All Applications
1 Repair Kit CHRA (Core)* 1
2 CHRA (Core) 1
4 Bearing Housing 1
5 Turbine Housing 1
6 Assembly, Turbine Wheel 1
7 Compressor Wheel 1
8 Compressor Housing 1
11 Journal Bearing* 2
12 Thrust Bearing* 1
13 Split Ring Seal, Turbine* 1
16 Split Ring Seal, Compressor* 1
28 V-Band Clamp, Turbine 1
31 Oil Slinger 1
32 O-Ring Seal, Bearing Housing* 1
33 Oil Baffle 1
36 Thrust Collar 1
38 Heat Sheild 1
41 O-Ring Seal, Compressor Housing* 1
43 Oil Seal Plate 1
53 Gasket, Oil Outlet 1
60 Plain Washer 1
61 Locknut, Compressor Wheel 1
62 Locknut, V-Band 1
64 Retaining Ring, Bearing* 2
66 Retaining Ring, Insert 1
91 Retaining Ring, Compressor Housing 1
96 Screw, V-band 1
113 Adaptor, Oil Inlet 1
114 O-Ring Seal, Oil Inlet 1
