Holtek HT66F004 User Manual

Rev. 1.71 140 April 11, 2017 Rev. 1.71 141 April 11, 2017
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
See Fig2
Symbol
Dimensions in inch
Min. Nom. Max.
A 0.945 0.965 0.985
B 0.275 0.285 0.295
C 0.120 0.135 0.150
D 0.110 0.130 0.150
E 0.014 0.018 0.022
F 0.045 0.050 0.060
G — 0.1BSC —
H 0.300 0.310 0.325
I — — 0.430
Symbol
Dimensions in mm
Min. Nom. Max.
A 24.00 24.51 25.02
B 6.99 7.24 7.49
C 3.05 3.43 3.81
D 2.79 3.30 3.81
E 0.36 0.46 0.56
F 1.14 1.27 1.52
G — 2.54 BSC —
H 7.62 7.87 8.26
I — — 10.92
