HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
• IFS0 Register – HT66F002/HT66F0025
Bit 7 6 5 4 3 2 1 0
Name — — STCK0PS STP0IPS — — INTPS1 INTPS0
R/W — — R/W R/W — — R/W R/W
POR — — 0 0 — — 0 0
Bit7~6 Unimplemented,readas"0"
Bit5 STCK0PS:STCK0PinRemappingControl
0:STCK0onPA7(default)
1:STCK0onPA6
Bit4 STP0IPS:STP0IPinRemappingControl
0:STP0IonPA6(default)
1:STP0IonPA0
Bit3~2 Unimplemented,readas"0"
Bit1~0 INTPS1, INTPS0:INTPinRemappingControl
00:INTonPA5(default)
01:INTonPA2
10:INTonPA3
11:INTonPA7
• IFS0 Register – HT66F003
Bit 7 6 5 4 3 2 1 0
Name PTCK1PS1 PTCK1PS0 STCK0PS STP0IPS PTP1IPS — INTPS1 INTPS0
R/W R/W R/W R/W R/W R/W — R/W R/W
POR 0 0 0 0 0 — 0 0
Bit7~6 PTCK1PS1, PTCK1PS0:PTCK1PinRemappingControl
00:PTCK1onPA4(default)
01:PTCK1onPA6
10:PTCK1onPA7
11:PTCK1onPB1
Bit5 STCK0PS:STCK0PinRemappingControl
0:STCK0onPA3(default)
1:STCK0onPA2
Bit4 STP0IPS: STP0IPinRemappingControl
0:STP0IonPA6(default)
1:STP0IonPA0
Bit3 PTP1IPS: PTP1IPinRemappingControl
0:PTP1IonPA5(default)
1:PTP1IonPB0
Bit2 Unimplemented,readas"0"
Bit1~0 INTPS1, INTPS0:INTPinRemappingControl
00:INTonPA3(default)
01:INTonPA2
10:INTonPA4
11:INTonPA5
