Holtkamp Electronics SUNCASH engl. techn. Stand 04.2016 4047_04.2016 V09.2019
- 6 -
5 Devicespecicdata
After the operating voltage has been applied, the display will
show for about 2 seconds: Holtkamp SunCash V x.x. It applies
to the description of the software version (X.x). This information
is subject to the technical development of the SunCash and your
order. For later enquiries and orders it would be helpful to know
this information.
Key number (imprinted on key)
Serial number (noted on the model plate)
Commission
Trader
Therefore it is necessary to write these numbers down, which
appear in the display, in the following table for later technical in-
quiries.
6 Generally technical data
Casing material sheet steel (casing 3 mm, door 5 mm)
Casing color RAL 9010 structured in pure white
Color stand/base acrylic, colored backprinted *
Door front 4 VA
Dimension housing h 980 mm x w 695 mm x d 380 mm
Total height 1760 mm
Stand area w 690 mm x d 380 mm
Electrical data 230 V, 50 - 60 Hz
Power absorption 50 VA
Cable entry from above and below
Temperature range 10°C - 40°C
Relative humidity 25 – 70 %
Protection class I by 230V~
Schutzart IP 20
Weight empty (without money) approximately 170 kg
Weight (with money) approximately 223 kg
Fuse board SI 2 315mA T
Attention: Fuses may only be replaced by ones with the
same values!
* Door front available on request in custom design
