Page #8 background imageLoading...
Page #8 background image
HOLUX M-1000 Bluetooth GPS Receiver Manual
7
Stop bit 1
II. Format. NMEA0183 V3.01 GPGGA (1time/1 sec), GPGSA (1 time/5 sec.),
GPGSV (1time /5 sec.), GPRMC (1time /1 sec.), GPVTG (1 time/1 sec), (GLL,
or MTK NMEA Command for optional).
III. Datum WGS84.
z Input/ Output Interface:
I. Compatible Bluetooth Serial Port Profile (SPP), Version1.2 and class 2(up
to 10 meter range).
II. In/Out Port. GPS signal (Out)/Command(In) with CMOS LevelMini USB
Type B Connector and Cable option
(a) GR230-A2 (USB data cable)
4.7. Physical
z Size 65 × 43 × 17.6 mm
z Weight < 53 g
z Operating Temperature-10 to + 60(under the un-charging condition);
Charging Temperature 0 to + 45
z Storage Temperature-20 to + 60
z Operating humidity 5% to 95% No condensing
4.8. Other Functions
z Bluetooth frequency: 2.4 ~2.48GHz
z Bluetooth Input Sensitivity: -85dBm
z Low sensitivity of receiving satellite signal
-159 dBm
z LED Functions Indicate Bluetooth status, GPS status, Battery Status and
Battery charging status
This Manual: http://www.manuallib.com/file/2551106

Other manuals for Holux M-1000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Holux M-1000 and is the answer not in the manual?

Holux M-1000 Specifications

General IconGeneral
Product colorBlack
WAAS capabilityYes
Channels quantity32 channels
GPS accuracy - position2.2, 5 m
GPS accuracy - velocity0.1 m/s
Bluetooth version1.2
Battery capacity50 mAh
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)5 - 95 %
Weight and Dimensions IconWeight and Dimensions
Depth43 mm
Width65 mm
Height17.6 mm
Weight53 g
