Holux M-1200XX User Manual

HOLUX M-1200XX Bluetooth GPS Receiver Manual
7
Data bit： 8
Parity： No
Stop bit： 1
II. Format. NMEA0183 V3.01： GPGGA (1time/1 sec), GPGSA (1 time/5 sec.),
GPGSV (1time /5 sec.), GPRMC (1time /1 sec.), GPVTG (1 time/1 sec), (GLL,
or MTK NMEA Command for optional).
III. Datum： WGS84.
 Input/ Output Interface:
I. Compatible Bluetooth Serial Port Profile (SPP), Version1.2 and class 2(up
to 10 meter range).
II. In/Out Port. GPS signal (Out)/Command(In) with CMOS Level。Mini USB
Type B Connector and Cable option：
(a) GR230-A2 (USB data cable)
4.7. Physical
 Size： 65 × 43 × 17.6 mm
 Weight： < 53 g
 Operating Temperature：-10 to + 60 (under the un℃℃ -charging condition);
Charging Temperature： 0 to + 45℃℃
 Storage Temperature：-20 to + 60℃℃
 Operating humidity： 5% to 95% No condensing
4.8. Other Functions
 Bluetooth frequency: 2.4 ~2.48GHz
 Bluetooth Input Sensitivity: -85dBm
 Low sensitivity of receiving satellite signal
： -159 dBm
 LED Functions： Indicate Bluetooth status, GPS status, Battery Status and
Battery charging status

Holux M-1200XX Specifications

General

Brand	Holux
Model	M-1200XX
Category	GPS
Language	English
