Holzstar KGZ210 E - Imprint

2 KGZ Series | Version 2.02 | EN
Imprint
Product identification
Chop- and Mitre Saw Item number
KGZ 210 E 5702210
KGZ 255 E 5702255
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt/Bamberg
Fax: 0049 (0) 951 96555 - 55
Email: info@holzstar.de
Internet: www.holzstar.de
Information about the operating instructions
Genuine operating instructions
Published: 03.08.2020
Version: 2.02
Language: English
Author: MS/FL
Copyright information
Copyright © 2020 Stürmer Maschinen GmbH, Hallstadt,
Germany.
Stürmer is the sole owner of the content of these operat-
ing instructions.
Forwarding and reproduction of this document as well as
use and notification of its content is not permitted without
explicit consent. Infringements will lead to claims for
damages.
Subject to technical modifications and changes.
Contents
Imprint..................................................... 2
Contents ................................................. 2
1 Introduction ............................................. 3
1.1 Copyright ............................................................ 3
1.2 Customer service................................................ 3
1.3 Disclaimer........................................................... 3
2 Safety ....................................................... 3
2.1 Legend of Symbols ............................................. 3
2.2 Operator responsibility........................................ 4
2.3 Requirements to Staff......................................... 4
2.4 Personal Protective Equipment ......................... 5
2.5 Safety Labels on the Chop- and Mitre Saw ........ 5
2.6 Safety Warnings for Lasers ................................ 6
2.7 General Safety Instruction for the Electrical Tools...6
2.8 General Safety Rules.......................................... 8
2.9 Additional Safety Rules for the Chop- and Mitre Saw...8
3 Intended Use ......................................... 10
4 Technical Data....................................... 11
4.1 Table................................................................. 11
4.2 Type Plate KGZ 210 E...................................... 12
5 Transport, Packaging and Storage...... 12
5.1 Delivery and Transport ..................................... 12
5.2 Packaging......................................................... 13
5.3 Storage ............................................................. 13
6 Description of the Device..................... 14
6.1 Scope of Delivery.............................................. 15
7 Setting up and Installation ................... 15
7.1 Set up the Chop- and Mitre Saw....................... 15
7.2 Electrical Connection........................................ 17
8 Operation the Chop- and Mitre Saw .... 17
8.1 Adjustment Options on the Model KGZ 210 E..... 18
8.2 Adjustment Options on the Model KGZ 255 E..... 21
8.3 Double mitre cut Model KGZ 255 E .................. 23
8.4 Setting the Maximum Cutting Depth
(Model KGZ 210 E and KGZ 255 E) ................. 24
8.5 Operation of the laser modelKGZ 255 E........... 25
8.6 Workpiece clamp .............................................. 25
8.7 Table extension ................................................ 25
9 Care, maintenance and repairs............ 26
9.1 Care after finish work........................................ 26
9.2 Replacement the Saw Blade ............................ 26
9.3 Electric brake modelKGZ 255 E ....................... 27
9.4 Maintenance and repairs .................................. 27
10 Troubleshooting.................................. 29
11 Disposal, reusing used machines ..... 29
11.1 Decommissioning ........................................... 29
11.2 Disposal via municipal collection points.......... 29
11.3 Disposal of electrical equipment..................... 30
11.4 Disposing of lubricants.................................... 30
12 Electrical Wiring Diagrams................. 30
13 Spare parts .......................................... 30
13.1 Spare parts orders.......................................... 30
13.2 Spare parts drawing KGZ 210 E..................... 31
13.3 Spare parts drawing KGZ 255 E..................... 32
14 EC Declaration of Conformity ............ 33
