HOMCOM A90-224 User Manual

12
No. Description
Spec
Qty NO. Description Spec Qty
1 Main Frame 1 25 Square Plug 20*20*1.5 Square tube 2
2 Strengthen tube 1 26 EVA 20*2*400 1
3 Right Upright post frame 1 27 Flat foot pad 27*16 2
4 Left Upright post frame 1 28 Front roller
∮
36*429*
∮
100*
∮
12*467 1
5
Double faced adhesive
tape
20*2*950 4 29 Rear roller
∮
36*406*
∮
12*457 1
6 Remoter 1 30 Cylinder
∮
22*160 length 100 2
7 Wrench 80*80*5 S5 1 31 Needle bearing
∮
10*
∮
24*4 2
8 Handle bar 1 32 Washer
∮
9*
∮
16*t1.5 6
9 Motor Seat 1 33 Screw M5*10 4
10 Running board t12*460*1010 1 34 Screw M8*12 S6 2
11 Running Belt t1.4*380*2260 1 35 Screw M8*16 S6 4
12 Ribbed belt 160-J5 1 36 Washer D8 6
13 Motor cover
546*260*62
466g
1 37 Screw M8*25 S6 1
14 Bottom cover board
546*260*90
637g
1 38 Screw M8*35 S6 2
15 Left End Cap
104*152*62
95g
1 39 Screw ST4.2*12 3
16 Right End Cap
104*152*62
95g
1 40 Screw ST4.2*16 6
17 Side Rail
83*58*975
1060g(single
）
2 41 Screw ST4.2*16 7
18 Cushion Pad 30*40*5 8 42 Screw M6*30 S4 6
19 Transport wheel
∮
52*
∮
8.5*22
Black
2 43 Screw M6*40 S4 2
20 Power cord buckle 6W3-4 Black 1 44 Bolt M6*50 S5 3
21 Damping foot pad
∮
60*53*M10 2 45 Nut M8 S13 4
22 Hand Grip
∮
25*
∮
31*350 1 46 Screw
M8*25 teeth length15
S6
2
23 Cushion pad
∮
8*
∮
18*19
4.2g
2 47 Power wire
3*0.75mm
2
10/15A 250V
Wire length 1.8Meter
1
24 Cushion block 24*35*11 6g 2 48 Nut M10 S17 2
PARTS LIST

HOMCOM A90-224 Specifications

General

Brand	HOMCOM
Model	A90-224
Category	Treadmill
Language	English
