14
GB
F D E
English
I P NL S DK N FIN GR H CZ RUS RO PL
SPECIFIC SAFETY RULES FOR
BRUSHCUTTER AND BLADE USE
■ Do not attempt to touch or stop the blade when it
is rotating.
■ A coasting blade can cause injury while it continues to
spin after the engine is stopped or throttle trigger
released. Maintain proper control until the blade has
completely stopped rotating.
■ Replace any damaged blade. Always make sure blade
is installed correctly and securely fastened before
each use. Failure to do so can cause serious injury.
■ Use only the manufacturer’s replacement TRI-ARC
blade intended for use on this brushcutter. Do not use
any other blade.
■ The TRI-ARC blade is suited for cutting pulpy weeds
and vines only. Do not use for any other purpose.
Never use the TRI-ARC blade to cut woody brush.
■ Exercise extreme caution when using the blade with this
unit. Blade thrust is the reaction which may occur when
the spinning blade contacts anything it cannot cut.
This contact may cause the blade to stop for an
instant, and suddenly “thrust” the unit away from the
object that was hit. This reaction can be violent enough
to cause the operator to lose control of the unit. Blade
thrust can occur without warning if the blade snags,
stalls or binds. This is more likely to occur in areas
where it is difficult to see the material being cut.
For cutting ease and safety, approach the weeds being
cut from the right to the left. In the event that an
unexpected object or woody stock is encountered, this
could minimise the blade thrust reaction.
■ Never cut any material over 13 mm (1/2 in) diameter.
■ Always wear the shoulder strap when using the
brushcutter and adjust to a comfortable operating
position. Maintain a firm grip on both handles while
cutting with a blade. Keep the blade away from body and
below waist. Never use the brushcutter with the blade
located 76 cm (30 in) or more above the ground level.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
SPECIFICATIONS
Weight
Without fuel, cutting attachment 5.58 kg
With blade 5.90 kg
With string head 5.77 kg
Fuel tank volume 425 cm
3
Cutting swath 457 mm
Engine displacement 30 cm
3
Maximum engine performance
(in accordance with ISO 8893) 0.78 kW
Maximum rotational frequency
of the spindle 10,000/min
-1
Engine Speed (rotational frequency)
at recommended max.
spindle rotational frequency 12,500/min
-1
Engine speed (rotational frequency)
at idle 2,000-2,500/min
-1
Fuel consumption (in accordance with ISO 8893) at max.
engine performance 0.52 kg/h
Specific fuel consumption (in accordance with ISO 8893)
at max. engine performance 0.47 kg/h
Vibration level idling
- Front Handle 4.9
- Rear Handle 5.8
Vibration level racing
- Front Handle 5.1
- Rear Handle . 6.2
Sound pressure level
(in accordance with EN ISO 11806:
1997, ISO 7917:1987) 99
Sound power level (in accordance
with ISO 10884) 113
DESCRIPTION
1. CUTTING LINE 30. BOTTOM CLAMP
2. GRASS DEFLECTOR 31. TOP CLAMP
3. LINE CUT-OFF BLADE 32. QUICK RELEASE TAB
4. ENGINE HOUSING 33. LATCH
5. STARTER GRIP 35. REAR HOUSING
6. THROTTLE TRIGGER 36. SILENCER GUARD
7. STRAP HANGER 37. SCREWS
8. SHOULDER STRAP 38. TORQUE WRENCH
9. KNOB 39. BENT END OF SILENCER
GUARD
10 BLADE GUARD 40. OPENING IN REAR HOUSING
11. TRI-ARC BLADE 41. MOUNTING BRACKET
12. GEAR HEAD 42. NOTCHES
13. SHAFT 43. LOCKING TABS
14. COUPLER 44. THREADED MOUNTING
PLATES
15. FRONT "J" HANDLE 45. SPANNER (16 mm)
16. IGNITION SWITCH 46. DRIVE CONNECTOR
17. THROTTLE INTERLOCK 47. SPOOL RETAINER
18. EXTENSION SHAFT 48. STRING HEAD
19. GUIDE RECESS 49. HOLDING PIN
20. POSITIONING HOLE 50. UPPER FLANGE WASHER
21. HANGER CAP 51. SPANNER (13 mm)
22. HOLE 52. BLADE NUT
23. BUTTON 53. CUPPED WASHER
24. BOLT 1/4 -20 x 1 in. 56. PRIMER BULB
25. BOLT 1/4 -20 x 1 1/2 in. 57. WARM START POSITION
26. SPACER 58. COLD START POSITION
27. FLAT WASHER 59. LEVER
28. LOCK WASHER 60. SPRING
29. HEX NUT 61. SLOTS
