Page 14
EDGER GUIDE OPERATION - TRIM ‘N EDGE
ONLY
See Figures 10 -11.
n Loosen the wing nut and slide the edger guide to adjust
it to the desired trimming length then retighten the wing
nut securely. Refer to “Edger Guide Assembly” earlier in
this manual for additional information.
n The edger guide allows the trimmer to be used as an edger
for cutting along sidewalks, driveways, flower beds, etc.
The edger guide is convenient to use and supports the
trimmer as it is being used as an edger.
n Be extremely careful when tilting the trimmer to use as an
edger. The muffler, and the exhaust from the muffler get
very hot during operation. Keep the muffler away from all
body parts. See Figure 11.
OPERATION
Fig. 10
WING NUT
EDGER GUIDE
Fig. 11
