Page 15
STARTING AND STOPPING
See Figure 12 - 13.
TO START A COLD ENGINE:
DO NOT squeeze the throttle trigger until the engine starts
and runs.
n Lay the trimmer on a flat, bare surface.
n PRIME - Press the primer bulb 7 times.
n SET the start lever to the START position.
n PULL the rope until the engine starts.
n Allow the engine to run for 15 seconds.
n Squeeze the throttle trigger.
NOTE: Squeezing the throttle trigger releases the start lever
to the RUN position.
TO START A WARM ENGINE:
PULL the rope until the engine starts.
TO STOP THE ENGINE:
Push and hold the STOP button until the engine stops.
Fig. 12
THROTTLE
TRIGGER
OPERATION
STARTING
INSTRUCTION
LABEL
Fig. 13
START
POSITION
RUN
POSITION
PRIMER BULB
START LEVER
START LEVER
STOP
BUTTON
