Specifications
■ Main Components
Overall length 2,110 mm (83.1 in)
Overall width
ED, ⅡED type
780 mm (30.7 in)
KO, ⅡKO type
760 mm (29.9 in)
Overall height 1,075 mm (42.3 in)
Wheelbase 1,450 mm (57.1 in)
Minimum ground
clearance
150 mm (5.9 in)
Caster angle 25° 30’
Trail 101 mm (4.0 in)
Curb weight
ED, ⅡED type
208 kg (459 lb)
KO, ⅡKO type
205 kg (452 lb)
Maximum weight capacity
*1
ED, ⅡED type
188 kg (414 lb)
KO, ⅡKO type
168 kg (370 lb)
Maximum luggage weight
*2
27 kg (60 lb)
Passenger capacity Rider and 1 passenger
Minimum turning radius 3.0 m (9.8 ft)
*1 : Including rider, passenger, all luggage, and accessories.
*2 : Includes the weight of the luggage and added accessories.
Displacement 649 cm
3
(39.6 cu-in)
Bore x stroke 67.0 x 46.0 mm (2.64 x 1.81 in)
Compression
ratio
11.4 : 1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Fuels containing
alcohol
ETHANOL up to 10 % by volume
Tank capacity 17.3 L (4.57 US gal, 3.81 Imp gal)
Battery
FTZ10S
12 V-8.6 Ah (10 HR) / 9.1 Ah (20 HR)
YTZ10
12 V-8.6 Ah (10 HR) / 9.1 Ah (20 HR)
Gear ratios
1st 3.071
2nd 2.352
3rd 1.888
4th 1.560
5th 1.370
6th 1.214
Reduction ratios
(primary / final)
1.690 / 2.800
20161220114015_32MJED100_eng_BOOK Page 118 Tuesday, December 20 2016 11:43:47 JST
Specifications
115
