Inspecting the Brake Pads
Check the condition of the brake pad wear
indicators.
The pads need to be replaced if a brake pad
is worn to the indicator.
1.
Front
Inspect the brake pads from below
the brake caliper.
u Always inspect both left and right
brake calipers.
2.
Rear
Inspect the brake pads from the rear
right of the motorcycle.
If necessary have the pads replaced by your
dealer.
Always replace both left and right brake pads
at the same time.
20161220114015_32MJED100_eng_BOOK Page 71 Tuesday, December 20 2016 11:43:47 JST
Brakes u Inspecting the Brake Pads
Maintenance
68
Front Rear
Brake Pad
Wear indicators
Disc
Brake Pad
Wear indicators
Disc
Brake Pad
Brake Pad
To Next Page
