Honda GCV160 User Manual

108
2009.01.10 E
E-22
CONTROL(1)
2
20) 16580-Z0M-810 BASE COMP., CONTROL ••••••••• - 1 - - - - - -------- -------- S2G7
- - - 1 - - - -------- 2130839 S1E1,S2E,S2E1
16580-Z0M-781 •••••••••••••••••••••••••••• - - - 1 1 - - 2112489 -------- A7E1,N7A1
- - - - 1 - - -------- -------- A7H1
16580-Z0M-811 •••••••••••••••••••••••••••• - - - 1 - - - -------- -------- S2E2,S3E9,S4E4,S4E9
- - - 1 - - - 2130840 -------- S1E1,S2E,S2E1
16580-Z0M-782 •••••••••••••••••••••••••••• - - - - - - 1 -------- -------- N7A1,N7S1
16580-Z0M-812 •••••••••••••••••••••••••••• - - 1 - - - - -------- -------- S2G7
21 16584-883-300 SPRING, CONTROL ADJUSTING ••• 1 1 1 1 - - 1 -------- -------- A7E1,N7A1,N7S1,S1E1,S2E,S2E1,S2E2,S2G7,S3E9,S4E4
S4E9
22 16599-ZG1-M10 COLLAR, STOPPER ••••••••••••• 1 1 1 1 - - 1 -------- -------- A7E1,N7A1,N7S1,S1E1,S2E,S2E1,S2E2,S2G7,S3E9,S4E4
S4E9
23 90016-ZE7-W00 SCREW, RECESSED, 5X28 ••••••• 1 1 1 1 - - 1 -------- -------- A7E1,N7A1,N7S1,S1E1,S2E,S2E1,S2E2,S2G7,S3E9,S4E4
S4E9
- - - - 1 - -
Ref.
No.
Part No. Description
Reqd. QTY
Parts catalogue code
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Serial No.
I 5

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
