Honda GCV160 User Manual

December 28,2009
CODE NO.
13ZM00E8
PARTS CATALOGUE NEWS
Honda Motor Co., Ltd. Service Division
PARTS CATALOGUE - CORRECTED
PARTS
CATALOGUE
NEWS
GCV160
GCV160A
GCV160A0
GCV160E
GCV160LE
GCV160LA
GCV160LA0
Printed in Japan NEWS NO. 020
Reqd.QTY
Block
No.
Ref.
No.
Note Part No. Description
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Serial No. Parts catalogue code
E-22 7 T 16580-ZM0-J22 BASE COMP., CONTROL .......... 1 1 - - - - - ------- ------- EHHB,N1J1,N1W2
T 16580-ZM0-020 .............................. 1 - - - - - - ------- ------- A2E4
1 - - - - - - 1177560 ------- A1A,A1C,A1E,A1J,A1P,A1U,A2A,A2C,A2E,A2U
A3E,A4E,N1,N2
- 1 - - - - - ------- ------- A1C,A1E,A2A,A2C,A3E
- - - 1 - - - ------- 2352103 A1P
T 16580-ZM0-802 .............................. 1 - - - - - - ------- ------- N1W,N1W1,N3U,N3V
1 - - - - - - 1177560 ------- N1D,N1E1,N1E2,N1U,N2D,N2E,N2E1,N2E2
N2E3,N2U
- 1 - - - - - ------- ------- N1E1
A 16580-ZM0-J23 .............................. - 1 - 1 - 1 1 ------- ------- BHH,NBL1,N1J1
T 16580-ZM0-030 .............................. - 1 1 - - 1 1 ------- ------- A1A,A1AS,A1AW,A1M
- - - 1 - - - 2352104 ------- A1P
A 16580-ZM0-803 .............................. - 1 1 1 - - - ------- ------- N1D,N1E2,N1U,N2U,N3U,N3V
- - - 1 - - - ------- ------- N1E1
E 16580-Z0L-J20 *PARTS NO. DELETION
E 16580-Z0L-000 *PARTS NO. DELETION
NOTE A:PART NO.CHANGE D:NEWLY PROVIDED E:PART NO.DELETION K:REQUIRED NO.CORRECTION L:APPLICATION SERIAL NO.CORRECTION
T:APPLICATION CORRECTION Z:REMARKS CHANGE
1/2

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
