2009.01.10 E
• The standard part fuel hose, general purpose hose and vinyl hose may be substituted by the coiled bulk part.
• When ordering the standard part fuel hose, general purpose hose and vinyl hose use the bulk part number written in the parts catalog in brackets ( ) underneath the part name.
• When exchanging the hose, cut and use at the specified length as mentioned in the part name.
(For the method of cutting the bulk part, and method of filling out orders etc., please refer to the instructions issued with the bulk part.)
Bulk part number of fuel hose, general purpose hose and vinyl hose.
CAUTION: It is DANGEROUS to confuse the fuel hose with the general purpose hose or vinyl hose.
Never use a general purpose hose or vinyl hose in place of a fuel hose or vice versa. Always use the correct bulk part in the parts catalogue, according
to the service manual or the instructions issued with the bulk part.
Fuel hose, general purpose hoses and vinyl hose
Bulk part number:
Refers to the bulk part.
Example: 9 5 0 0 1 - 7 5 0 0 1 - 5 0 M
Marking code (fuel hose and general purpose hose)
Change code (Vinyl hose)
Indicates number mark or change sequence, however, the code for the bulk part must be strictly 0 (zero).
Types of code:
• Fuel hose 2: Red outside braid
(3 mm inside dia. only)
5: Black inside braid
3: Red (3 mm inside dia. only)
4: Ash gray with red stripe
(3 mm inside dia. only)
6: Black
• General hose 1: Ash gray
2: Ash gray
3: Black
5: Black
• Vinyl hose 1: Clear
2: Black
3: Light red
6: Light red
7: Pale black
Lengths:
001: 1 m (standard)
003: 3 m
008: 8 m
I.D code: (fuel hose and general purpose hose)
30: 3.0 mm
35: 3.5 mm
45: 4.5 mm
50: 5.0 mm
55: 5.3 mm, 5.5 mm
65: 6.5 mm
70: 7.0 mm
75: 7.3 mm, 7.5 mm
80: 8.0 mm
11: 11 mm
91: 12 (outside dia. 15) mm
92: 12 (outside dia. 16) mm
12: 12 (outside dia. 17) mm
14: 14 mm
17: 17 mm
Hose type:
1: Fuel hose
3: Vinyl hose
5: General hose
}
Application or specification of some parts is not settled.
ID./OD. code: (vinyl hose)
01: ID. 2.9, OD. 6.8 mm
03: ID. 3.0, OD. 6.0 mm
05: ID. 3.5, OD. 6.5 mm
07: ID. 4.0, OD. 7.0 mm
08: ID. 4.5, OD. 6.5 mm
09: ID. 4.5, OD. 8.0 mm
12: ID. 5.0, OD. 7.0 mm
10: ID. 5.0, OD. 8.0 mm
11: ID. 5.0, OD. 9.0 mm
14: ID. 6.0, OD. 9.0 mm
17: ID. 7.0, OD. 9.0 mm
19: ID. 7.0, OD. 11.0 mm
21: ID. 8.0, OD. 9.0 mm
23: ID. 8.0, OD. 12.0 mm
25: ID. 9.0, OD. 11.0 mm
27: ID. 9.0, OD. 13.0 mm
33: ID. 10.0, OD. 14.0 mm
36: ID. 11.0, OD. 13.0 mm
37: ID. 11.0, OD. 15.0 mm
38: ID. 12.0, OD. 13.0 mm
39: ID. 12.0, OD. 14.0 mm
40: ID. 12.0, OD. 16.0 mm
43: ID. 13.0, OD. 15.0 mm
45: ID. 14.0, OD. 18.0 mm
50: ID. 16.0, OD. 19.0 mm
55: ID. 17.5, OD. 20.5 mm
60: ID. 22.0, OD. 27.0 mm
C15
