Instruments & Controls
15
Gauges & Indicators
The gauges and indicators on your motorcycle keep you informed, alert you to
possible problems, and make your riding safer and more enjoyable. Refer to the
gauges and indicators frequently. Their functions are described on the following
pages.
USA: Speedometer, odometer & tripmeter read in miles.
Canada: Speedometer, odometer & tripmeter read in kilometers.
tachometer red zone
tachometer
reverse system indicator
neutral indicator
overdrive indicator
CRUISE ON indicator
CRUISE SET indicator high beam indicator
fuel gauge
speedometer
right turn signal indicator
left turn signal indicator
PGM-FI malfunction
indicator lamp (MIL)
coolant
temperature
gauge
low oil pressure
indicator
low tire pressure
indicator
side stand indicator
low fuel indicator
anti-lock brake
system (ABS)
indicator (Models
equipped with
ABS)
tire pressure
monitoring system
(TPMS) indicator
