Section 1: General Information
5
Testing the System
After installation the security system should be tested. Refer to the control panel installation
instructions for procedures to test the entire system.
WEEKLY TESTING IS REQUIRED TO ENSURE PROPER OPERATION OF THIS SYSTEM
Specifications
Mechanical Dimensions: 9.1" (23.2cm) x 9.1" (23.2cm) x 2.2" (5.7cm)
Weight: without battery: 1.5 lbs (700g)
with battery: 3.3 lbs (1500g)
Input Power 9VDC, 2.5A Power Adapter (Resideo # 300-11260)
Current Drain Stand-Alone Unit ................................ 70mA idle, 240mA average active
With PROLTE Module ....................... 72mA idle, 240mA average active
With Wi-Fi Module .............................. 74mA idle, 320mA average active
With Dialer Capture Module .......... 76mA idle, 245mA average active
Wi-Fi & Dialer Capture Modules .. 80mA idle, 325mA average active
Backup Battery
4V, 6.5AH, (Resideo # R300-11454)
Expected Battery Life: 5 Years (approx.)
NOTE: The sealed lead acid battery used for backup will have reduced life
expecta
ncy when exposed to elevated temperatures. The useful life of
the battery at 25ºC (77ºF) is approximately 4 years. At 35ºC (95ºF)
this will drop to 2 years and at 45ºC (113ºF) 1 year. Battery life
expectancy should be taken into account when locating the radio.
Fault Trigger
Output
Open collector, 12VDC, 0.25W max
Ethernet
Network Standard: IEEE 802.3u compliant
Data Rate: 10Base-T (10Mbps) / 100Base-T (100Mbps) with auto detect
Ethernet Cable: Cat. 5 (min), MDI / MDI-X auto crossover
Environmental
Operating temperature: 0ºC to +49ºC (32°F to 120°F)
Storage temperature: –40ºC to +70ºC (-104°F to 158°F)
Humidity: 0 to 95% relative humidity, non-condensing
for UL installations: 0% to 85%; for ULC installations 0% to 93%
Altitude: to 10,000 ft. operating, to 40,000 ft. storage
Frequency Bands
LTE
Band 2
LTE
Band 4
LTE
Band 5
LTE
Band 12
LTE
Band 13
LTEM-PV
X X
LTEM-PA
X X X
Output Power
LTE Class 5 20dBm (conducted)
