Honeywell Home T5+ User Manual

20 21
Option # Option Name Option Value (factory default in bold)
220 Cool Stages/
Compressor
Stages
(#200=Conv./
#200=HP
(149.14 kW))
0, 1, 2
Note: Select how many Cool or Compressor stages of your equipment
the thermostat will control. Maximum of 2 Cool/Compressor Stages.
221 Heat Stages/
Aux/E Stages
(#200=Conv./
#200=HP
(149.14 kW))
Heat Stages: 0, 1, 2
Aux/E stages: 0, 1
Note: Select how many Heat or Aux/E stages of your equipment the
thermostat will control. Maximum of 2 Heat Stages for conventional
systems. Maximum of 1 Aux/E stage for systems with more than 1
heating equipment type.
Note: For a complete listing of the ISU setting options, please see the T5+
Smart Product data file at resideo.com
Equipment Setup Options
Electrical Ratings
Terminal Voltage (50Hz/60Hz) Running Current
W Heating 20 Vac - 30 Vac 0.02 A - 1.0 A
W2 (Aux) Heating 20 Vac - 30 Vac 0.02 A - 1.0 A
E Emergency Heat 20 Vac - 30 Vac 0.02 A - 0.5 A
Y Compressor Stage 1 20 Vac - 30 Vac 0.02 A - 1.0 A
Y2 Compressor Stage 2 20 Vac - 30 Vac 0.02 A - 1.0 A
G Fan 20 Vac - 30 Vac 0.02 A - 0.5 A
O/B Changeover 20 Vac - 30 Vac 0.02 A - 0.5 A
L/A Input 20 Vac - 30 Vac 0.02 A - 0.5 A

Honeywell Home T5+ Specifications

General

Model	Honeywell Home T5+
Category	Thermostat
Connectivity	Wi-Fi
Display	Touchscreen
Programmable	Yes
Energy Star Certified	Yes
Geofencing	Yes
Smart Home Compatibility	Amazon Alexa, Google Assistant, Apple HomeKit
Voice Control	Yes
Warranty	1-year limited warranty
Stages	1 Heat / 1 Cool
Remote Control	Yes, via app
Energy Saving Features	Smart alerts, adaptive recovery
Dimensions	4.06 in. H x 4.06 in. W x 1.06 in. D
Compatibility	Works with most 24V heating and cooling systems
Power Source	C-Wire (Common Wire) required
