Honeywell 4820 User Manual

8 - 8
H - Histogram Stretch
Increases the contrast of the transmitted image. Not available with some
image formats.
0H No stretch
(default)
1H Histogram stretch
I - Invert Image
Invert image is used to rotate the image around the X or Y axis.
1ix Invert around the X axis (flips picture upside down)
1iy Invert around the Y axis (flips picture left to right)
Example of Histogram Stretch at 0H: Example of Histogram Stretch at 1H:
Example of image
with Invert Image set to
1ix:
Example of image not
inverted:
Example of image
with Invert Image set
to 1iy:

Honeywell 4820 Specifications

General

Wavelength	617 nm
Optical sensor resolution	752 pixels
Bluetooth	Yes
Standard interfaces	USB
Battery type	Lithium Ion
Input voltage	3.7 V
Certification	FCC Part 15, RSS-210, CE, GS, NOM-NYCE, COFETEL, C-Tick
Product color	Black, Grey
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	255 g
