Honeywell 7000 - PEM Wiring Diagram and Address Setup; RF Expansion Module (RFEM) Installation

HONEYWELL 7000 SOLID STATE ALARM SYSTEM
69-1192—1
8
ON ON ON ON ON ON ON ON
OFF OFF OFF
ON ON ON ON OFF OFF OFF OFF
ON ON ON
ON ON OFF OFF ON ON OFF OFF
ON ON OFF
ON OFF ON OFF OFF OFF ON OFF
ON OFF ON
12 3 456 7891011
1
2
3
4
1
2
3
4
S1
TB1
TB2
OFF ON
S1
S1 SETS PEM ADDRESS #
S1 SHOWN SET FOR ADDRESS #1
MAXIMUM OF 11 PEMs ON A SYSTEM
PEM ADDRESS #
11
10
9
8
7
6
5
4
3
2
1
1 2 3 4 5 6 7 8 9 10 11
GND P1 P2 P3 P4 GND P5 P6 P7 P8– P8+
NO
EOLR
NC
NO
EOLR
NC
ALL EOLR =
3.3K 1/4W 5%
TYP WIRING: POINT 1-7 WIRING: POINT 8
GND
GND
+13.8 VDC
HBUS–
HBUS+
RELAY 1
TO
CONTROL
PANEL
GOLDEN VALLEY, MINN.
RELAY 2
NO
NC
C
NO
NC
C
BLK
RED
GRN
YEL
M10902
RELAY:
CURRENT DRAIN ≤ 40 mA
CONTACT RATING:
RESISTIVE
2A @ 30 VDC
0.4A @ 30 VAC
INDUCTIVE
1A @ 30 VDC
0.2A @ 30 VAC
LABEL 2480341 REV B
PEM
SYSTEM 7000
SEE INSTALLATION MANUAL
PEM Wiring
1. Use four-conductor AK4500A cable to connect the PEM
to other HBus devices.
2. Connect the PEM wires to the control panel according
to the wiring diagram with the unit. See Fig. 6.
Each PEM has a unique, four digit, address. Fig. 6 lists the
PEM address number and switch settings. The Honeywell
7000 System can support up to 11 PEM.
RFEM Installation
The RFEM provides additional rf protection points for the
Honeywell 7000 System. Only one RFEM can be used per
system.
Mount the RFEM plastic box within 250 feet (76 meters) of
the control panel if using 22 AWG wire or 500 feet (152
meters) if using 18 AWG wire.
Remove the RFEM circuit board from the RFEM plastic box
(if installed) and use the RFEM plastic box to mark the
mounting screw locations on the wall or plywood. Use two
screws to mount the RFEM plastic box. Insert the RFEM
circuit board into the RFEM plastic box. See Fig. 7.
Fig. 6. PEM wiring diagram.
