PIR Motion Sensors
5
IS-280CM
360° Ceiling
Mount PIR
“Commercial features and
performance for overhead
installations.”
Features
• Mounting heights from 8’ to 12’
• Low profile housing
• Microprocessor-based signal
processing
• Sealed optics chamber
• Can be mounted on a single gang-box
• Cover tamper
.• Range: 45’ dia. @ 10’ mounting height
50’ dia. @ 12’ mounting height
• Detectable walk rate: 0.5’ - 10’/sec
• Signal Proc.: 1, 2, 3, or 4 pulse count
• Temp comp: Advanced dual-slope
• Alarm relay: Form A
• Input voltage: 9-30VDC
• Standby current: 17mA
• Indicators: Three red LEDs for 360°
viewing
• Operating temp: 14°F to 122°F
• Dimensions: 4.9” Diameter x 1.5”H
IS-290CM-W/IS-290CM-N
Ceiling Mount PIR
“Ideal for commercial
installations where wall
mounting is difficult.”
Features
• Mounting heights from 8’ to 12’
• Fully adjustable mirror optics
• Low profile housing
• Microprocessor-based signal
processing
• Can be mounted on a single gang-box
• Cover tamper
Specifications:
• Range: 40’ x 45’ (IS-290CM-W)
65’ x 7’ (IS-290CM-N)
@ 10’ mounting height
• Detectable walk rate: 0.5’ - 10’/sec
• Signal Proc.: 2 or 4 pulse count
• Temp comp: Advanced dual-slope
• Alarm relay: Form A
• Input voltage: 10-30VDC
• Standby current: 25mA
• Indicators: Red (alarm), yellow (alarm
memory) LEDs
• Operating temp: 14°F to 122°F
• Dimensions: 6” Diameter x 1.81”D
