DUAL TEC
®
Motion Sensors
DT-7235T
DUAL TEC
®
Motion Sensor
“Economical sensor
combines K-Band, pet
immunity and error-free
installation.”
Accessories
• Swivel Bracket - SMB10
• Ceiling Bracket - SMB10C
• Tampered Swivel Bracket - SMB10T
Features
• Pet immune to 100 lbs.
• Exclusive K-Band microwave
technology
• Fast and simple installation with no
adjustments
• Microwave supervision
• Uniform Sensitivity Optics
• Zero Clearance black bug guard
• Tamper
Specifications:
• Range: 35’ x 35’
• Microwave Freq: K-Band, 24.125GHz
• Detectable walk rate: 0.5’ - 10’/sec
• Signal Proc.: No adjustments required
• Temp comp: Standard
• Alarm relay: Form A
• Input voltage: 7.5-16VDC
• Standby current: 25mA
• Indicators: Red LED
• Operating temp: 14°F to 131°F
• Dimensions: 4.685”H x 2.795”W
x 1.654”D
DT-7435
DUAL TEC
®
Motion Sensor
“Pet immune protection that
incorporates the latest
processing technology.”
Accessories
• Swivel Bracket - SMB10
• Ceiling Bracket - SMB10C
• Tampered Swivel Bracket - SMB10T
Features
• Pet immune to 100 lbs.
• Exclusive K-Band microwave
technology
• DualCore micro-based processing
• Concurrent Diagnostics
• Digital microwave adaptive thresholds
• Digital fluorescent light filter
• Uniform Sensitivity Optics
• Zero Clearance black bug guard
• Tamper
• Also available with Form C
as DT-7435C
Specifications:
• Range: 35’ x 35’
• Microwave Freq: K-Band, 24.125GHz
• Detectable walk rate: 0.5’ - 10’/sec
• Signal Proc.: Intermediate, Standard
• Temp comp: Advanced dual-slope
• Alarm relay: Form A
• Input voltage: 7.5-16VDC
• Standby current: 25mA typical
• Indicators: Tri-color LED
• Operating temp: 14°F to 131°F
• Dimensions: 4.685”H x 2.795”W
x 1.654”D
7
IN04004 Sensor_Guide.qxd 7/19/05 12:35 PM Page 18
