IS-2260
Pet Immune PIR
"The only pet immune
PIR with range extended
to 60 ft."
Accessories
• Long Range Lens 100’x20’, 0-900-053-02
• 10’ mtg. height lens 60’x120’, 0-900-053-01
• Swivel Bracket - SMB10
• Ceiling Bracket - SMB10C
• Tampered Swivel Bracket - SMB10T
Features
• 60’ x 120’ coverage, plus lookdown zone
• Pet immunity to 40 lbs.
• ASIC signal processing
• Bi-directional temp comp
• Ultra-low current (<4mA)
• Uniform Sensitivity Optics
• Totally silent relay
• Zero Clearance black bug guard
• 7.5 or 10’ mounting height
• Available with tamper as IS-2260T
Specifications:
• Range: 60’ x 120’
• Detectable walk rate: 0.5’ - 10’/sec
• Signal Proc.: Intermediate, Std, Harsh
• Temp comp: Advanced dual-slope
• Alarm relay: Form A
• Input voltage: 8-14VDC
• Standby current: 4mA
• Indicators: Red LED
• Operating temp: 14°F to 122°F
• Dimensions: 4-3/8"L x
2-1/4"W x 1-1/2"D
AURORA
Pet Immune PIR
"Pet immunity with
distinctive styling."
Accessories
• Long Range Lens 75’x10’ - Aurora-LR
Features
• Pet immunity to 40 lbs.
• ASIC signal processing
• Bi-directional temp comp
• Ultra-low current (<4mA)
• Split-Zone Optics
• Totally silent relay
• Bug guard
• 6.5 - 9’ mouting height
• Available with tamper as AURORA-T
• Available in 6-pack as AURORA-PK
Specifications:
• Range: 35’ x 45’
• Detectable walk rate: 0.5’ - 10’/sec
• Signal Proc.: Intermediate, Std, Harsh
• Temp comp: Advanced dual-slope
• Alarm relay: Form A
• Input voltage: 8-14VDC
• Standby current: 4mA
• Indicators: Red LED
• Operating temp: 14°F to 122°F
• Dimensions: 2.9"W x 4.1"H x 1.5"D
PIR Motion Sensors
2
