Honeywell 7800 SERIES

RM7888A 7800 SERIES RELAY MODULE
32-00214—01 8
Fig. 7. Ultraviolet detectors (minipeepers).
Fig. 8. Ultraviolet detectors (minipeepers).
6 FOOT
[1.83 METER]
LEAD
WIRES (2)
3-5/8 (92)
1/2
(13)
1-27/64
(36)
3/8
(10)
7/8
(22)
9/16
(14)
M1944D
MOUNTING
BRACKET
4
(102)
4 (102)
3/8 INCH NPT
1 INCH NPT
7/8 (22) OPENING
FOR 1/2-INCH CONDUIT
ALLOW 9 INCHES (228 MILLIMETERS)
CLEARANCE TO SWING OUT THE DETECTOR
FOR LENS CLEANING OR SERVICING.
1
M5083C
1-1/16 (27)
2-1/4
(57)
2-1/4
(57)
4-27/32 (123)
1-13/32 (188)
10-9/32 (261)
2-5/16
(58)
29/32 (23)
3/4 (19)
1-19/32
(41)
2-11/16
(68)
7-5/8 (194)
C7076A
