2.4.3 TWO--AXIS VERSIONS
The following figures shows the two--axis FCCs, with and without altitude preselect capability. The
last figure shows all KC 140 display segments.
NOTE
Lamp is only on --5xx3 and --7xx3 versions and above.
FIGURE 2--2 TWO--AXIS FCC (--5XXX VERSIONS)
FIGURE 2--3 TWO--AXIS FCC W/ALTITUDE PRESELECT
AND ALERTING (--7XXX VERSIONS)
FIGURE 2--4 FULL KAP 140 DISPLAY (LAMP TEST)
