1.4 UNITS AND ACCESSORIES
A complete DME installation requires a KN 63 DME (066-1070-00/01), a KDI 572 master indicator
(066-1069-00 or 01) or KDI 574 Master Indicator (066-1069-04), a KA 60/61 antenna, and one or
two external control heads (see section 1.3, channeling sources). The KDI 572 is available with
either 14/28 volt lighting (066-1069-00) or 5 volt lighting (066-1069-01). Use of the KDI 573 slave
indicator (066-1069-02) is optional. A KN 63 installation kit (050-01766-0000) and KDI 572 instal-
lation kit (050-01740-0000) are required. A KDI 573 installation kit (050-01740-0001) is needed if
a KDI 573 is used. A KDI 574 installation kit (050-01740-0002) is needed if a KDI 574 is used.
KN 63 Installation Kit (050-01766-0000)
TABLE 1-3 KN 63 INSTALLATION KIT
KDI 572: Installation Kit (050-01740-0000)
KDI 573: Installation Kit (050-01740-0001)
KDI 574: Installation Kit (050-01740-0002)
PART NUMBER DESCRIPTION QTY
030-00005-0000 CONN BNC TED 4-10-4 2
030-01094-0056 CONN MOLEX (24P) 1
030-01107-0015 CONN PINS (15) 1
047-04218-0001 HOLD DOWN BAR 2
047-04219-0001 MOUNTING RACK 1
075-00021-0001 HOLD DOWN CLAMP 1
078-00054-0000 COMPRESSION SPRING 1
088-00752-0000 CONN HOOD 1
089-02015-0037 NUT HEX 8-32 4
089-05442-0010 SCR 8-32 FHP 4
089-05529-0032 SCR FHP 1
089-05909-0007 SCR 8-32 PHP 4
089-06541-0000 SCR 4-40 PHP 2
089-08111-0034 WASHER SL #8 5
091-00109-0001 CABLE TIE 1
