BENDIX/KING KN 63
Rev 4, October/2004 00176I04.TDC Page 1-3
0 = Connected to Remote Control Common
1 = Open
TABLE 1-2 DME CHANNELING CODES
SHIFTED BCD 2 x 5 SLIP
Frequency
MHz
M8 M4 M2 M1 MA ME MC MD M0 M1 M2 M3
108 0 0 0 0 0 1 1 0 1 1 0 1
109 0 0 0 1 0 0 1 1 1 1 1 0
110 0 0 1 0 1 0 1 1 0 1 1 1
111 0 0 1 1 0 1 1 1 0 0 1 1
112 0 1 0 0 0 1 0 1 0 0 0 1
113 0 1 0 1 1 1 0 1 1 0 0 0
114 0 1 1 0 1 1 1 0 0 1 0 0
115 0 1 1 1 1 1 0 0 1 0 1 0
116 1 0 0 0 1 0 0 1 0 1 0 1
117 1 0 0 1 1 0 1 0 0 0 1 0
K800 K400 K200 K100 KA KE KC KD K0 K1 K2 K3
.0X 0 0 0 0 1 0 1 1 0 0 1 1
.1X 0 0 0 1 0 1 1 1 0 0 0 1
.2X 0 0 1 0 0 1 0 1 0 0 0 0
.3X 0 0 1 1 1 1 0 1 1 0 0 0
.4X 0 1 0 0 1 1 1 0 1 1 0 0
.5X 0 1 0 1 1 1 0 0 0 1 1 0
.6X 0 1 1 0 1 0 0 1 1 0 1 1
.7X 0 1 1 1 1 0 1 0 1 1 0 1
.8X 1 0 0 0 0 1 1 0 1 1 1 0
.9X 1 0 0 1 0 0 1 1 0 1 1 1
K50 K50 K50
.X0 1 1 1
.X5 0 0 0
