Honeywell CENTRA LINE LION CLLIONLC01 - LON WORKS Bus Topologies; C-Bus Topologies; Accessories

Planning LION System
EN1Z-0921GE51 R0709
12
LONWORKS Bus Topologies
The LONWORKS Bus is a 78-kilobit serial link that uses
transformer isolation so that the bus wiring does not have a
polarity. I.e. it is not important which of the two LONWORKS
Bus terminals are connected to each wire of the twisted pair.
The L
ONWORKS Bus does not need to be shielded on the
controller module side.
The LONWORKS Bus can be wired in daisy chain, star, loop
or any combination thereof as long as the maximum wire
length requirements are met.
Configuration
The recommended configuration is a daisy chain with two
bus terminations. This layout allows for max. L
ONWORKS
Bus lengths, and its simple structure presents the least
number of possible problems, particularly when adding on to
an existing bus.
See also “L
ONWORKS Mechanisms”, Product Literature no.:
EN0B-0270GE51.
C-Bus Topologies
Via the C-Bus up to 30 C-Bus devices (e.g., controllers, etc.)
can communicate with one another and a PC central. The
C-Bus must be connected via the individual controllers
(open ring).
Note
Star connection is not allowed because uncontrollable line
reflections may occur.
Instead of LION Controllers, other C-Bus controllers (e.g.,
the Excel 500, Excel 100, PANTHER) can also be
connected.
LION
Excel 100 Excel 500
PANTHER
Fig. 4 C-Bus topology Excel 5000
Accessories
Besides the auxiliary parts of Table 5 on page 7, the
following accessories are available.
Preconfigured Connection Cables
Type
Connecting
CLLIONLC01 with
Features
XW882
CLMMI00N22 Operator
Interface
5 m, shielded,
RJ45 plug with clip
XW582
+ XW586
CLMMI00N22 Operator
Interface
See XW582 and
XW586
XW884
Adapter cable for Excel
500/600 Controllers
0.2 m, shielded,
RJ45 – 9 pin sub-D
XW885 Laptops
3 m, shielded,
RJ45 plug with clip
XW585
+ XW586
Laptops
See XW582 and
XW586
XW586 Modems
1.8 m, RJ45 – 9 pin
sub-D
Table 14 Preconfigured connection cables
XW882 Cable Details
12
3678
4
5
CLMMI00N22
WIRING
TERMINALS
XW882
SHIELD
LOOSE
ENDS
R
x
D
G
N
D
+
5
V
E
T
x
D
Y
E
L
L
O
W
G
R
A
Y
(
n
o
t
u
s
e
d
)
B
R
O
W
N
G
R
E
E
N
W
H
I
T
E
1
4
3
2
RJ45 plug with clip at front
+5V
Fig. 5 CLLIONLC01/CLMMI00N22 cable details
XW884 Cable Details
12
3678
4
5
RS232 plug
sub-D female
SHIELD
X
W884
6
7
8
9
1
2
3
4
5
R
x
D
R
T
S
T
x
D
G
N
D
RJ45 plug with clip at front
+5V
Fig. 6 CLLIONLC01/Excel 500/600 cable details
