4 - 1
4
Using the Scan Image Engine
Overview
The Dolphin terminal houses a compact image engine that instantly reads popular 1D and 2D bar codes
and supports omni-directional aiming and decoding for greater flexibility in real-world settings. The
image engine can also capture black and white digital images, such as signatures and pictures of dam-
aged inventory.
With the latest CMOS-based technology, the engine works like a digital camera and enables black and
white digital image capture, signature capture, and reading of OCR characters.
Angled Imaging
All imagers are installed at a 25 degree downward-facing angle for enhanced comfort and maneuverabil-
ity while scanning.
Laser Safety
See Laser Safety on page 1-1.
N5603 Beam Divergence Angle
LED Safety
See LED Safety on page 1-2.
Image Engine Specifications
Engines Horizontal Beam Divergence Angle
(degrees)
Vertical Beam Divergence Angle
(degrees)
N5603SR/HD
18.1 14.3
N5603ER
13.1 9.9
Engines 1D 2D Image Capture Aiming Pattern Omni-Directional Aiming
N5603SR/ER/HD
YYY
N5603 Red High-Vis
Aiming Pattern (page 4-5)
See Laser Safety on
page
1-1.
Y
N5600SR/ER/HD
YYY
N5600 Green Aiming
Beam (page 4-5)
Y
