EC7830A, RM7830A, EC7850A, RM7850A 7800 SERIES RELAY MODULES
11 32-00198—01
a
See Table 2.
b
2000 VA maximum connected load to relay module.
c
Honeywell has tested this output at 9.8A at PF = 0.5, 58.8A inrush for 100,000 cycles
(EN298 approval does not require this test).
d
Total load current, excluding Burner/Boiler Motor and Firing Rate Outputs cannot exceed 5A, 25A inrush.
e
Total load current, excluding Burner/Boiler Motor and Firing Rate Outputs cannot exceed 5A, 25A inrush for 250,000
cycles.
f
Can also be 24 Vac, 3A at PF = 0.5.
g
Transformer does not apply to UV flame sensor models C7061A1020, C7061A1079 and C7061F1003 (combined with
R7861-series flame amplifiers), which have internal selectable terminal block to connect 230V shutter output directly.
Table 4. EC7850A/RM7850A Terminal Ratings.
Terminal
No. Abbreviation Description RM7850A (120 Vac)
EC7850A (220/230/240
Vac)
G—
Flame Sensor Ground.
a
——
Earth G —
Earth Ground.
a
——
N — Line Voltage Common
(Neutral)
——
3 AL Alarm (Normally Open) 1A, 10A inrush for 5000
cycles.
1A, 10A inrush for 5000
cycles.
4 L1 Line Voltage Supply (L1) 120 Vac (+10%/-15%),
50/60 Hz (±10%).
b
220/230/240 Vac (+10%/-
15%), 50/60 Hz (±10%).
b
5 FAN Burner/Blower Motor
4A at PF = 0.5, 20A inrush.
c
4A at PF = 0.5, 20A inrush.
6 RT Limits and Burner Control 1 mA. 1 mA.
7 LD2 Airflow Switch Input 5A. 5A.
8 PV1 Pilot Valve 1 (Interrupted)
4A at PF = 0.5, 20A inrush.
d
4A at PF = 0.5, 20A inrush.
e
9MV Main Fuel Valve
4A at PF = 0.5, 20A inrush.
d
4A at PF = 0.5, 20A inrush.
e
10 IGN Ignition 2A at PF = 0.2. 2A at PF = 0.2.
F (11) — Flame Signal 60 to 220 Vac, current
limited.
136 to 220 Vac, current
limited.
12 HI Firing Rate High Fire
0.5A at PF = 0.5.
f
0.5A at PF = 0.5.
f
13 COM Firing Rate Common
0.5A at PF = 0.5.
0.5A at PF = 0.5.
f
14 MOD Firing Rate Modulate
0.5A at PF = 0.5.
f
0.5A at PF = 0.5.
f
15 LO Firing Rate Low Fire
0.5A at PF = 0.5.
f
0.5A at PF = 0.5.
f
16 — Alarm (Normally Closed) 1A, 10A inrush for 5000
cycles; carry 5A for 250,000
cycles.
1A, 10A inrush for 5000
cycles; carry 5A for 250,000
cycles.
17 ES2 Preignition Interlock Input 1 mA. 1 mA.
18 ES1 Low Fire Switch Input 1 mA. 1 mA.
19 ES3 High Fire Switch Input 1 mA. 1 mA.
20 LOS Lockout Input 1 mA. 1 mA.
21 PV2 Pilot Valve 2 (Intermittent)
4A at PF = 0.5, 20A inrush.
d
4A at PF = 0.5, 20A inrush.
e
22 SHTR Shutter Shutter drive for dynamic
self-check flame sensor.
Shutter drive for dynamic
self-check flame sensor.
g
