EXCEL 5000™ SYSTEM STYLED CABINET RINGS AND SUBPANELS
6-3/8
(162)
24
8-1/2
(610)
(216)
1
ADD 1 IN. (25 MM) TO THESE DIMENSIONS FOR
ROUGH-IN OPENING
C7080
Fig. 2. Ring dimensions in in. (mm).
SECURE WITH
1/4 IN. (6) DIAMETER
MOUNTING BOLT
OR SCREW (4)
(OBTAINED LOCALLY)
SECURE WITH
1/4 IN. (6) DIAMETER
MOUNTING BOLT
OR SCREW (4)
(OBTAINED LOCALLY)
21-3/4
(552)
16
(406)
5/16
(8)
1-5/16
(33)
5/8 DIA.
(16)
35-3/4
(908)
16
(406)
FULL-SIZED
CABINET
38 (965)
1
-or-
SMALL-SIZED
CABINET
24
(610)
1
1
SMALL-SIZED RING FULL-SIZED RING
C7081
Fig. 3. Ring mounting hole locations and sizes (dimensions in in. (mm)).
95-7487—1 2
