Honeywell EXCEL 5000 Installation Instructions

EXCEL 5000™ SYSTEM STYLED CABINET RINGS AND SUBPANELS
DIMENSIONS SAME
BOTH ENDS
HOLE CONDUIT SIZE
A 1-1/2 and 2
B
1
C 3/4
D 1/2
2-3/8 IN. (60) SQUARE KNOCKOUT
FOR HONEYWELL RACEWAY
FRONT
7-3/4 (197)
9-3/4 (248)
5-1/2 (140)
2-1/2 (64)
12 (305)
DIMENSIONS SAME
BOTH SIDES
A
A
B
B
C
D
C
D
A
A
B
B
D
D
C
C
A
3
(76)
A
A
A
15-5/8
(397)
D D
D D
C7082
Fig. 4. Conduit knockout locations and sizes for small-sized Ring (dimensions in in. mm)).
DIMENSIONS SAME
BOTH ENDS
3
(76)
FRONT A
A
A
A
2-3/8 IN. (60) SQUARE KNOCKOUT
FOR HONEYWELL RACEWAY
7-3/4 (197)
9-3/4 (248)
5-1/2 (140)
2-1/2 (64)
CONDUIT SIZE
A
B
C
D
1-1/2 and 2
1
3/4
1/2
HOLE
12 (305)
A
A
B
B
C
D
C
D
D D
A
A
B
B
D
D
C
C
D D
34-1/4
(870)
C7083
Fig. 5. Conduit knockout locations and sizes for full-sized Ring (dimensions in in. (mm)).
3 95-7487—1
