Read Status Operating Instructions
Pressing 3 while viewing Print Screen #1 allows the user to print the Walktest summary which will list the total of each type of input activa-
tion.
Pressing 1 while viewing Print Screen #2 allows the user to print the detector data for each addressable smoke detector connected to the sys-
tem. A printout, similar to the following example, will be generated if an optional printer is connected to the FACP.
Chamber Value
The Chamber value should be within the indicated range for the following smoke detectors:
• SD355CO, SD355, SD350(T) D350P(R) and SD300(T) Addressable Photoelectric Smoke Detectors: 405 - 2100 (obscuration of
1.00%/ft to 3.66%/ft.)
• CP355, CP350, and CP300 Addressable Ionization Smoke Detectors: 750 - 2100 (obscuration of 0.50%/ft. to 1.44%/ft.)
If the addressable smoke detector’s Chamber reading is not within the acceptable range, clean the detector and check the Chamber value
again. If the reading is still not within the acceptable range, immediately replace the detector.
Drift Compensation
Drift compensation uses software algorithms that identify and compensate for long-term changes in the data readings from each addressable
smoke detector. These long-term changes in detector data readings are typically caused by dirt and dust accumulation inside the smoke
chamber. Drift compensation performs the following functions:
• Samples photoelectric smoke detectors every 6 seconds and ionization smoke detectors every 3 seconds
• Allows a smoke detector to retain its original ability to detect actual smoke and resist false alarms, even as dirt and dust accumulate
• Reduces maintenance requirements by allowing the control panel to automatically perform the periodic sensitivity measurements
required by NFPA Standard 72
The FACP software also provides filters to remove transient noise signals, usually caused by electrical interference.
Maintenance Alert
The software determines when the drift compensation for a detector reaches an unacceptable level that can compromise detector perfor-
mance. When a detector reaches an unacceptable level, the control panel indicates a maintenance alert. Table 4.1 summarizes the three levels
of maintenance alert:
DEVICE # DEVICE TYPE % DRIFT COMP CHAMBER TIME/DATE
1D001 SMOKE (PHOTO) 20 1281 12:01 AM 01-08-2016
1D002 SMOKE (PHOTO) 20 1281 12:01 AM 01-08-2016
1D003 SMOKE (PHOTO) 21 1259 12:01 AM 01-08-2016
1D004 SMOKE (PHOTO) 20 1309 12:02 AM 01-08-2016
1D005 SMOKE (PHOTO) 21 1281 12:02 AM 01-08-2016
1D006 SMOKE (PHOTO) 20 1322 12:02 AM 01-08-2016
1D007 SMOKE (PHOTO) 20 1280 12:02 AM 01-08-2016
1D008 SMOKE (PHOTO) 20 1215 12:02 AM 01-08-2016
1D009 SMOKE (PHOTO) 20 1310 12:02 AM 01-08-2016
Maintenance Level: FACP Status Displays: Indicates:
Low Chamber Value
INVREP
A hardware problem in the detector
Maintenance Alert
DIRTY1
Dust accumulation that is near but below the allowed
limit. DIRTY 1 indicates the need for maintenance
before the performance of the detector is
compromised
Maintenance Urgent
DIRTY2
Dust accumulation above the allowed limit.
Table 4.1 Maintenance Alert Levels
